Pneumatic Three Way Ball Valve

Pneumatic Three Way Ball Valve means a regular three-way Ball valve with a pneumatic actuator. Pneumatic Three Way Ball Valves are designed for quick opening and closing. A well-engineered combination of a powerful pneumatic actuator, fitted to heavy duty high performance ball valve.

Send Inquiry

Product Description

Bulk Pneumatic Three Way Ball Valve which Can be Customized From Our Factory in China
1.What is the Pneumatic Three Way Ball Valve

Pneumatic Three Way Ball Valve means a regular three-way Ball valve with a pneumatic actuator. Pneumatic Three Way Ball Valves  are designed for quick opening and closing. A well-engineered combination of a powerful pneumatic actuator, fitted to heavy duty high performance ball valve.
Pneumatic actuated 3-way stainless steel flanged ball valve is used for on-off control of water, air, oil, and other media compatible in industry field with the materials of construction.


Pneumatic Three Way Ball Valve

2.Specification for Pneumatic Three Way Ball Valve

The Pneumatic Three Way Ball Valve comprises with PTFE or PPL seats. The Pneumatic actuator offers single acting or Double acting options. Double acting actuators use an air pressure signal (80-120 PSI) to open and close the valve. Single acting (Spring return) actuators use an air pressure signal to open and springs to close the valve. The Pneumatic Three Way Ball Valve will fail closed upon loss of air signal. They rotate 90 degrees from fully open to closed. This unit gives you an exceptional combination that offers trouble free operation coupled with high performance.

3.Technical Parameter of Pneumatic Three Way Ball Valve

Nominal Diameter: DN15 to DN200
Nominal Pressure: 1.6Mpa- 6.3Mpa
Body Material: Stainless Steel


4.How does the Pneumatic Three Way Ball Valve work

Pneumatic Three Way Ball Valve works by turning the handle, which rotates a ball in the valve body, to align the cut-out channels in the ball with the inlets and outlets of the valve. The "L" shape cut-out of the ball on an L-port valve sends fluid through 90 degrees from one port to another. The "T" shape cut-out of the ball on a T-port valve can also send from one port to another, but can also be rotated so that the T aligns with the "T" shape of the valve and all three ports are mixed.


Pneumatic Three Way Ball Valve
